Handy bagged swarm catcher with closure to retrieve swarms

Handy bagged swarm catcher with closure to retrieve swarms

-

-

-

-

-

-

RADIAL stainless steel Extractor for 45 Honey super combs or 20 nest D.B. 1mm thick stainless steel drum,tig welded double stainless steel reinforcing band, bottom with full frontal outlet drain, sleeve for Ø 50 cut tap (code QI R04I not included), SATIN FINISHED FLOWERED STAINLESS STEEL. Extractor bottom with accumulation of about 200kg honey. Upper bar for fixing stainless steel shaft bearing. Three stainless steel legs. Lids, one in transparent polycarbonate and one in stainless steel, attached with stainless steel hinges. Safety lock at lid. Stainless steel motor mounts. 1 Hp motor, housed under the drum. Speed reducer applied on de basket shaft. Electronic programmer with membrane panel. Power supply 230V-0.75Kw.

RADIAL stainless steel Extractor for 45 Honey super combs or 20 nest D.B. 1mm thick stainless steel drum,tig welded double stainless steel reinforcing band, bottom with full frontal outlet drain, sleeve for Ø 50 cut tap (code QI R04I not included), SATIN FINISHED FLOWERED STAINLESS STEEL. Extractor bottom with accumulation of about 200kg honey. Upper bar for fixing stainless steel shaft bearing. Three stainless steel legs. Lids, one in transparent polycarbonate and one in stainless steel, attached with stainless steel hinges. Safety lock at lid. Stainless steel motor mounts. 1 Hp motor, housed under the drum. Speed reducer applied on de basket shaft. Electronic programmer with membrane panel. Power supply 230V-0.75Kw.

Optional variable speed motorization : - ELOBA MOTOR + 550,00€ (QI S86) or - MOTOR REG.ELECTRONIC + 510,00€(QI S134) Extractors "KIT" Free wheel transmission and brake Transparent polycarbonate lids fixed with hinges Transmission holder crossbar and lids, stainless steel Castle in stainless steel or nylon with fiberglass Thrust bearing for shaft in BRONZE Rounded bottom with semi-total discharge Stainless steel full diameter filter Stainless steel tie( art. QI S51-52-S109-S110-S111-S117-S123) Stainless steel ripener 110 kg with tap art. QI R11-stainless steel handles Stainless steel hardware

Optional variable speed motorization : - ELOBA MOTOR + 550,00€ (QI S86) or - MOTOR REG.ELECTRONIC + 510,00€(QI S134) Extractors "KIT" Free wheel transmission and brake Transparent polycarbonate lids fixed with hinges Transmission holder crossbar and lids, stainless steel Castle in stainless steel or nylon with fiberglass Thrust bearing for shaft in BRONZE Rounded bottom with semi-total discharge Stainless steel full diameter filter Stainless steel tie( art. QI S51-52-S109-S110-S111-S117-S123) Stainless steel ripener 110 kg with tap art. QI R11-stainless steel handles Stainless steel hardware

-

-

-

-

-

-

Optional variable speed motorization : - ELOBA MOTOR (QI S86) or - ELECTRONIC REGISTRATION MOTOR (QI S122) SERIES 2008 IS A NEW SERIES OF PLANTS DESIGNED FOR "SINGLE-BLOCK" HONEY EXTRACTION. In one machine, you have everything you need in a honey extraction room, uncapping ,operculum treatment , accumulation of uncapped combs , honey extraction and decanting of honey. The most obvious advantages are: smaller footprint, convenience in processing steps, with higher yield and reduction of 'inevitable dripping of honey on the floor. The 2008 series is produced in different versions from the hobbyist beekeeper to the professional.

Optional variable speed motorization : - ELOBA MOTOR (QI S86) or - ELECTRONIC REGISTRATION MOTOR (QI S122) SERIES 2008 IS A NEW SERIES OF PLANTS DESIGNED FOR "SINGLE-BLOCK" HONEY EXTRACTION. In one machine, you have everything you need in a honey extraction room, uncapping ,operculum treatment , accumulation of uncapped combs , honey extraction and decanting of honey. The most obvious advantages are: smaller footprint, convenience in processing steps, with higher yield and reduction of 'inevitable dripping of honey on the floor. The 2008 series is produced in different versions from the hobbyist beekeeper to the professional.

-

-

LANGSTROTH stainless steel bench for uncapping with tank cm.100x51x40 with lectern with lid and stainless steel legs Stainless steel tank Stainless steel filter for decanting operculum perforated sheet stainless steel tap nylon cod. QI R11,Ø 40 mm Stainless steel lectern cod. QI L11 Stainless steel legs Stainless steel lid Height bench for uncapping 80cm

LANGSTROTH stainless steel bench for uncapping with tank cm.100x51x40 with lectern with lid and stainless steel legs Stainless steel tank Stainless steel filter for decanting operculum perforated sheet stainless steel tap nylon cod. QI R11,Ø 40 mm Stainless steel lectern cod. QI L11 Stainless steel legs Stainless steel lid Height bench for uncapping 80cm

-

-

-

-

Beehives D.B. 10 frames painted with fixed anti-varroa net bottom complete with: Nest; Honey super; 10 nest frames with wax foil; 9 honeycomb frames with wax goflio cover with 4-position disc mounted; 10-cm-high galvanized sheet metal lid lined with wood and faestile on the bottom; canopy the galvanized sheet metal; plastic transport mask; galvanized pinwheels; small metal door; 3 connection angles; spacers mounted in nest and Honey super; fixed antivarroa net bottom with galvanized sheet metal bottom removable from back; seasoned fir wood, 25mm thick; walls assembled with screws; carrying handles; Frame rest

Beehives D.B. 10 frames painted with fixed anti-varroa net bottom complete with: Nest; Honey super; 10 nest frames with wax foil; 9 honeycomb frames with wax goflio cover with 4-position disc mounted; 10-cm-high galvanized sheet metal lid lined with wood and faestile on the bottom; canopy the galvanized sheet metal; plastic transport mask; galvanized pinwheels; small metal door; 3 connection angles; spacers mounted in nest and Honey super; fixed antivarroa net bottom with galvanized sheet metal bottom removable from back; seasoned fir wood, 25mm thick; walls assembled with screws; carrying handles; Frame rest

-

-

-

-

To make your own beeswax candle you will need: - a silicone mold- a wick of appropriate thickness- a rubber band- a toothpick- silicone (Spray) - optional 1) Preparing the mold:We recommend spraying the mold inside with silicone spray which will make it easier to remove the candle at the end of the process. Insert the wick in the center from the bottom and pop it out from the top. Secure the mold with rubber bands to keep it tightly closed. Tie a wick to the toothpick and rest the latter on the top edge. 2) Fill the mold ocn the wax: Melt the wax in a preferably enameled pot, pour it into the mold when it has reached a temperature of 50°C. Pour it slowly into the mold. The time for the wax to solidify depends on the size of the mold and the amount of wax used. 3) Take the candle out of the mold:When the wax is cold, remove the rubber bands, open the mold and take out the candle. Remove the toothpick and cut the wick at the base of the candle, while on the top leave the wick 1 cm long. Spray the candle with silicone spray to give it shine.

To make your own beeswax candle you will need: - a silicone mold- a wick of appropriate thickness- a rubber band- a toothpick- silicone (Spray) - optional 1) Preparing the mold:We recommend spraying the mold inside with silicone spray which will make it easier to remove the candle at the end of the process. Insert the wick in the center from the bottom and pop it out from the top. Secure the mold with rubber bands to keep it tightly closed. Tie a wick to the toothpick and rest the latter on the top edge. 2) Fill the mold ocn the wax: Melt the wax in a preferably enameled pot, pour it into the mold when it has reached a temperature of 50°C. Pour it slowly into the mold. The time for the wax to solidify depends on the size of the mold and the amount of wax used. 3) Take the candle out of the mold:When the wax is cold, remove the rubber bands, open the mold and take out the candle. Remove the toothpick and cut the wick at the base of the candle, while on the top leave the wick 1 cm long. Spray the candle with silicone spray to give it shine.

-

-

OPTIONAL:
10 L stainless steel funnel (Cod. SY 1106640)
On-board start microswitch (Cod. SY 110045)

Microchip-controlled pump motor that ensures anti-drip function
The DANA api MATIC 1000 is a gear pump filler. A powerful low-voltage DC motor drives the gear pump with the help of a helical gear. The motor is controlled by computer electronics, which also ensures perfect anti-drip function. The filler has 20 filling programs with settings for weight, calibration factor and other filling parameters. The machine works precisely and is easy to program for different substances. As a pump, the machine works in both directions and can be set to different speeds. All parts that come into contact with the substance are made of food-grade plastic or stainless steel and are easy to disassemble and clean.
The stand is made of sturdy stainless steel and has a plastic jar guide, which you can rest the jar on, so that it is centered exactly under the nozzle. The jar guide can also be adjusted back and forth depending on the diameter of the jar.
The stand can be adjusted to 13 different heights in 0.5 cm increments.
The stand can be used for jars that have a full height of between 3.5 cm and 23.5 cm. It measures 37 x 32 x 41 cm and weighs 4.6 kg.

TECHNICAL DATA

Machine type: computer-controlled gear pump
Filling capacity: 10 g - 10 Kg (honey)
Weight unit: ml / g / oz
Accuracy: +/- 2 g
Pump capacity: approx. 270 kg/hour
Programs: over 20 options to program
Power supply: 90-264VAC 50/60Hz
Power: 230 W
Noise level: the sound pressure level of the pump is less than 70 dB(A)
Weight: approx. 10.5 kg
Dimensions: 33 x 31 x 18.5 cm
Connections: 1½" - 40 mm BS hose connection on both sides of the pump

The machine is fitted with:
110075- Foot switch
110059- Counterflow valve
115815- Dosing syringe 0-60 ml
500110F- Nut for BS connection 1½" - 40 mm
110065C- Complete cutting cross ø20
110165- 1½" - 40 mm hose
110110A- Curved BS connection 1½" - 40 mm
110175- Hose connector 1½" - 40 mm
With the machine you receive a spare parts set included containing:
2 x 110065D Cross cut Ø20
2 x 110072 Black rubber diaphragm
2 x 500212 Gasket BS 1½
2 x 502740 Hand-fitting nuts for head

2 x 508037 O-ring 37x2 NBR 70

1 x 508082 O-ring 82x2 NBR 70

OPTIONAL:
10 L stainless steel funnel (Cod. SY 1106640)
On-board start microswitch (Cod. SY 110045)

Microchip-controlled pump motor that ensures anti-drip function
The DANA api MATIC 1000 is a gear pump filler. A powerful low-voltage DC motor drives the gear pump with the help of a helical gear. The motor is controlled by computer electronics, which also ensures perfect anti-drip function. The filler has 20 filling programs with settings for weight, calibration factor and other filling parameters. The machine works precisely and is easy to program for different substances. As a pump, the machine works in both directions and can be set to different speeds. All parts that come into contact with the substance are made of food-grade plastic or stainless steel and are easy to disassemble and clean.
The stand is made of sturdy stainless steel and has a plastic jar guide, which you can rest the jar on, so that it is centered exactly under the nozzle. The jar guide can also be adjusted back and forth depending on the diameter of the jar.
The stand can be adjusted to 13 different heights in 0.5 cm increments.
The stand can be used for jars that have a full height of between 3.5 cm and 23.5 cm. It measures 37 x 32 x 41 cm and weighs 4.6 kg.

TECHNICAL DATA

Machine type: computer-controlled gear pump
Filling capacity: 10 g - 10 Kg (honey)
Weight unit: ml / g / oz
Accuracy: +/- 2 g
Pump capacity: approx. 270 kg/hour
Programs: over 20 options to program
Power supply: 90-264VAC 50/60Hz
Power: 230 W
Noise level: the sound pressure level of the pump is less than 70 dB(A)
Weight: approx. 10.5 kg
Dimensions: 33 x 31 x 18.5 cm
Connections: 1½" - 40 mm BS hose connection on both sides of the pump

The machine is fitted with:
110075- Foot switch
110059- Counterflow valve
115815- Dosing syringe 0-60 ml
500110F- Nut for BS connection 1½" - 40 mm
110065C- Complete cutting cross ø20
110165- 1½" - 40 mm hose
110110A- Curved BS connection 1½" - 40 mm
110175- Hose connector 1½" - 40 mm
With the machine you receive a spare parts set included containing:
2 x 110065D Cross cut Ø20
2 x 110072 Black rubber diaphragm
2 x 500212 Gasket BS 1½
2 x 502740 Hand-fitting nuts for head

2 x 508037 O-ring 37x2 NBR 70

1 x 508082 O-ring 82x2 NBR 70

-

-

-

-
